风华磁珠-CBW大电流磁珠系列型号

我公司是风华高科授权代理商一站式电子元器件整合供应商，欢迎咨询！联系人何先生: 13712101206（微信同号） QQ：3003173476

在线咨询全国热线
0769-85325266

产品描述

产品型号	标称阻抗（Ω）	直流电阻RDC（Ω）max	测试频率(MHz)	测试电压（mV）	偏差范围	额定电流(A)	L (mm)	W (mm)	T (mm)
CBW321609U302T	3000	0.9	50	50	±25%	0.2	3.2±0.20	1.6±0.20	0.9±0.20
CBW201209U252T	2500	0.45	50	50	±25%	0.6	2.0±0.20	1.2±0.20	0.9±0.20
CBW160808U252T	2500	0.65	100	50	±25%	0.4	1.6±0.20	0.8±0.20	0.8±0.20
CBW321609U252T	2500	0.9	50	50	±25%	0.2	3.2±0.20	1.6±0.20	0.9±0.20
CBW201209U252T-1	2500	0.45	50	50	±25%	0.6	2.0±0.20	1.2±0.20	0.9±0.20
CBW201209U222T	2200	0.4	100	50	±25%	0.7	2.0±0.20	1.2±0.20	0.9±0.20
CBW201209U202TA02	2000	0.4	100	50	±25%	0.7	2.0±0.20	1.2±0.20	0.9±0.20
CBW321609U202T	2000	0.7	50	50	±25%	0.3	3.2±0.20	1.6±0.20	0.9±0.20
CBW160808U202T	2000	0.6	100	50	±25%	0.4	1.6±0.20	0.8±0.20	0.8±0.20
CBW201209U202T	2000	0.4	100	50	±25%	0.7	2.0±0.20	1.2±0.20	0.9±0.20
CBW201209U202TA01	2000	0.4	100	50	±25%	0.7	2.0±0.20	1.2±0.20	0.9±0.20
CBW321609U182T	1800	0.6	50	50	±25%	0.5	3.2±0.20	1.6±0.20	0.9±0.20
CBW160808U182T	1800	0.55	100	50	±25%	0.4	1.6±0.20	0.8±0.20	0.8±0.20
CBW201209U152TA12	1500	0.4	100	50	±25%	0.7	2.0±0.20	1.2±0.20	0.9±0.20
CBW321609U152T	1500	0.45	50	50	±25%	0.5	3.2±0.20	1.6±0.20	0.9±0.20
CBW201209U152T	1500	0.4	100	50	±25%	0.7	2.0±0.20	1.2±0.20	0.9±0.20
CBW201209U152TA01	1500	0.4	100	50	±25%	0.7	2.0±0.20	1.2±0.20	0.9±0.20
CBW160808U152T	1500	0.55	100	50	±25%	0.4	1.6±0.20	0.8±0.20	0.8±0.20
CBW321609U122T	1200	0.35	100	50	±25%	1.5	3.2±0.20	1.6±0.20	0.9±0.20
CBW160808U122T	1200	0.45	100	50	±25%	0.5	1.6±0.20	0.8±0.20	0.8±0.20
CBW201209U122T	1200	0.28	100	50	±25%	0.8	2.0±0.20	1.2±0.20	0.9±0.20
CBW100505U102TA01	1000	0.9	100	50	±25%	0.25	1.0±0.15	0.5±0.15	0.5±0.15
CBW160808U102T	1000	0.4	100	50	±25%	0.5	1.6±0.20	0.8±0.20	0.8±0.20
CBW321609U102T	1000	0.25	100	50	±25%	2	3.2±0.20	1.6±0.20	0.9±0.20
CBW201209U102TA01	1000	0.25	100	50	±25%	1	2.0±0.20	1.2±0.20	0.9±0.20
CBW322513U102T	1000	0.28	100	50	±25%	2	3.2±0.20	2.5±0.20	1.3±0.20
CBW060303X102T	1000	1.25	100	50	±25%	0.2	0.6±0.03	0.3±0.03	0.3±0.03
CBW201209U102T	1000	0.25	100	50	±25%	1	2.0±0.20	1.2±0.20	0.9±0.20
CBW100505U102T	1000	0.9	100	50	±25%	0.25	1.0±0.15	0.5±0.15	0.5±0.15
CBW201209U801TA01	800	0.25	100	50	±25%	1	2.0±0.20	1.2±0.20	0.9±0.20
CBW321609U801T	800	0.25	100	50	±25%	2	3.2±0.20	1.6±0.20	0.9±0.20
CBW322513U801T	800	0.23	100	50	±25%	2	3.2±0.20	2.5±0.20	1.3±0.20
CBW160808U801T	800	0.35	100	50	±25%	0.5	1.6±0.20	0.8±0.20	0.8±0.20
CBW201209U801T	800	0.25	100	50	±25%	1	2.0±0.20	1.2±0.20	0.9±0.20
CBW100505U801T	800	0.8	100	50	±25%	0.25	1.0±0.15	0.5±0.15	0.5±0.15
CBW100505U801TA01	800	0.8	100	50	±25%	0.25	1.0±0.15	0.5±0.15	0.5±0.15
CBW451616U601T	600	0.2	100	50	±25%	1.5	4.5±0.20	1.6±0.20	1.6±0.20
CBW100505U601TA01	600	0.6	100	50	±25%	0.3	1.0±0.15	0.5±0.15	0.5±0.15
CBW201209U601T	600	0.22	100	50	±25%	1.5	2.0±0.20	1.2±0.20	0.9±0.20
CBW160808U601TA01	600	0.3	100	50	±25%	1	1.6±0.20	0.8±0.20	0.8±0.20
CBW322513U601T-01	600	0.18	100	50	±25%	2	3.2±0.20	2.5±0.20	1.3±0.20
CBW322513U601T	600	0.18	100	50	±25%	2	3.2±0.20	2.5±0.20	1.3±0.20
CBW160808U601T	600	0.3	100	50	±25%	1	1.6±0.20	0.8±0.20	0.8±0.20
CBW453215U601T	600	0.1	100	50	±25%	1	4.5±0.20	3.2±0.20	1.5±0.20
CBW321609U601T	600	0.2	100	50	±25%	2	3.2±0.20	1.6±0.20	0.9±0.20
CBW100505U601T	600	0.6	100	50	±25%	0.3	1.0±0.15	0.5±0.15	0.5±0.15
CBW060303X601T	600	0.85	100	50	±25%	0.25	0.6±0.03	0.3±0.03	0.3±0.03
CBW321609U501T	500	0.2	100	50	±25%	2	3.2±0.20	1.6±0.20	0.9±0.20
CBW322513U501T	500	0.12	100	50	±25%	3	3.2±0.20	2.5±0.20	1.3±0.20
CBW201209U501T	500	0.22	100	50	±25%	1.5	2.0±0.20	1.2±0.20	0.9±0.20
CBW160808U501T	500	0.3	100	50	±25%	1	1.6±0.20	0.8±0.20	0.8±0.20
CBW453215U501T	500	0.1	100	50	±25%	1	4.5±0.20	3.2±0.20	1.5±0.20
CBW100505U501T	500	0.6	100	50	±25%	0.3	1.0±0.15	0.5±0.15	0.5±0.15
CBW451616U501T	500	0.2	100	50	±25%	1.5	4.5±0.20	1.6±0.20	1.6±0.20
CBW321609U391T	390	0.17	100	50	±25%	2	3.2±0.20	1.6±0.20	0.9±0.20
CBW100505U301T	300	0.4	100	50	±25%	0.4	1.0±0.15	0.5±0.15	0.5±0.15
CBW451616U301T	300	0.09	100	50	±25%	2	4.5±0.20	1.6±0.20	1.6±0.20
CBW321609U301TA01	300	0.15	100	50	±25%	2	3.2±0.20	1.6±0.20	0.9±0.20
CBW322513U301T	300	0.08	100	50	±25%	3	3.2±0.20	2.5±0.20	1.3±0.20
CBW321609U301T	300	0.15	100	50	±25%	2	3.2±0.20	1.6±0.20	0.9±0.20
CBW453215U301T	300	0.06	100	50	±25%	2	4.5±0.20	3.2±0.20	1.5±0.20
CBW160808U301T	300	0.2	100	50	±25%	1.2	1.6±0.20	0.8±0.20	0.8±0.20
CBW201209U301T	300	0.13	100	50	±25%	2	2.0±0.20	1.2±0.20	0.9±0.20
CBW160808U301TA01	300	0.2	100	50	±25%	1.2	1.6±0.20	0.8±0.20	0.8±0.20
CBW060303X241T	240	0.38	100	50	±25%	0.35	0.6±0.03	0.3±0.03	0.3±0.03
CBW201209U221T-01	220	0.13	100	50	±25%	2	2.0±0.20	1.2±0.20	0.9±0.20
CBW160808U221T	220	0.18	100	50	±25%	1.2	1.6±0.20	0.8±0.20	0.8±0.20
CBW321609U221T	220	0.11	100	50	±25%	2.5	3.2±0.20	1.6±0.20	0.9±0.20
CBW322513U221T	220	0.08	100	50	±25%	3	3.2±0.20	2.5±0.20	1.3±0.20
CBW451616U221T	220	0.08	100	50	±25%	2	4.5±0.20	1.6±0.20	1.6±0.20
CBW453215U221T	220	0.06	100	50	±25%	2	4.5±0.20	3.2±0.20	1.5±0.20
CBW100505U221T	220	0.3	100	50	±25%	0.7	1.0±0.15	0.5±0.15	0.5±0.15
CBW201209U221T	220	0.13	100	50	±25%	2	2.0±0.20	1.2±0.20	0.9±0.20
CBW100505U201T	200	0.3	100	50	±25%	0.7	1.0±0.15	0.5±0.15	0.5±0.15
CBW201209U181T	180	0.12	100	50	±25%	2	2.0±0.20	1.2±0.20	0.9±0.20
CBW321609U181T	180	0.1	100	50	±25%	2.5	3.2±0.20	1.6±0.20	0.9±0.20
CBW160808U181T	180	0.15	100	50	±25%	1.2	1.6±0.20	0.8±0.20	0.8±0.20
CBW322513U181T	180	0.08	100	50	±25%	3	3.2±0.20	2.5±0.20	1.3±0.20
CBW322513U151T	150	0.08	100	50	±25%	4	3.2±0.20	2.5±0.20	1.3±0.20
CBW321609U151T	150	0.1	100	50	±25%	2.5	3.2±0.20	1.6±0.20	0.9±0.20
CBW451616U151T	150	0.06	100	50	±25%	3	4.5±0.20	1.6±0.20	1.6±0.20
CBW100505U151T	150	0.25	100	50	±25%	0.7	1.0±0.15	0.5±0.15	0.5±0.15
CBW160808U151T	150	0.15	100	50	±25%	1.2	1.6±0.20	0.8±0.20	0.8±0.20
CBW201209U151T	150	0.1	100	50	±25%	2.5	2.0±0.20	1.2±0.20	0.9±0.20
CBW453215U151T	150	0.04	100	50	±25%	3.5	4.5±0.20	3.2±0.20	1.5±0.20
CBW321609U121T	120	0.07	100	50	±25%	3	3.2±0.20	1.6±0.20	0.9±0.20
CBW322513U121T	120	0.06	100	50	±25%	4	3.2±0.20	2.5±0.20	1.3±0.20
CBW453215U121T	120	0.03	100	50	±25%	4	4.5±0.20	3.2±0.20	1.5±0.20
CBW160808U121T	120	0.14	100	50	±25%	1.3	1.6±0.20	0.8±0.20	0.8±0.20
CBW451616U121T	120	0.06	100	50	±25%	3	4.5±0.20	1.6±0.20	1.6±0.20
CBW060303X121T	120	0.23	100	50	±25%	0.45	0.6±0.03	0.3±0.03	0.3±0.03
CBW201209U121T	120	0.08	100	50	±25%	2.5	2.0±0.20	1.2±0.20	0.9±0.20
CBW100505U121T	120	0.25	100	50	±25%	0.7	1.0±0.15	0.5±0.15	0.5±0.15
CBW453215U101T	100	0.03	100	50	±25%	4	4.5±0.20	3.2±0.20	1.5±0.20
CBW321609U101T	100	0.07	100	50	±25%	3	3.2±0.20	1.6±0.20	0.9±0.20
CBW100505U101T	100	0.2	100	50	±25%	0.9	1.0±0.15	0.5±0.15	0.5±0.15
CBW160808U101T	100	0.12	100	50	±25%	1.4	1.6±0.20	0.8±0.20	0.8±0.20
CBW451616U900T	90	0.06	100	50	±25%	3	4.5±0.20	1.6±0.20	1.6±0.20
CBW453215U800T	80	0.02	100	50	±25%	4	4.5±0.20	3.2±0.20	1.5±0.20
CBW322513U800T	80	0.03	100	50	±25%	5	3.2±0.20	2.5±0.20	1.3±0.20
CBW201209U800T	80	0.06	100	50	±25%	3	2.0±0.20	1.2±0.20	0.9±0.20
CBW321609U800T	80	0.07	100	50	±25%	3	3.2±0.20	1.6±0.20	0.9±0.20
CBW060303X800T	80	0.18	100	50	±25%	0.5	0.6±0.03	0.3±0.03	0.3±0.03
CBW451616U800T	80	0.05	100	50	±25%	3	4.5±0.20	1.6±0.20	1.6±0.20
CBW160808U800T	80	0.1	100	50	±25%	1.5	1.6±0.20	0.8±0.20	0.8±0.20
CBW453215U700T	70	0.02	100	50	±25%	4	4.5±0.20	3.2±0.20	1.5±0.20
CBW321609U600T	60	0.04	100	50	±25%	3	3.2±0.20	1.6±0.20	0.9±0.20
CBW321609U600T-01	60	0.04	100	50	±25%	3	3.2±0.20	1.6±0.20	0.9±0.20
CBW201209U600T	60	0.05	100	50	±25%	3	2.0±0.20	1.2±0.20	0.9±0.20
CBW160808U600T	60	0.1	100	50	±25%	1.5	1.6±0.20	0.8±0.20	0.8±0.20
CBW100505U600T	60	0.13	100	50	±25%	1	1.0±0.15	0.5±0.15	0.5±0.15
CBW322513U600T	60	0.03	100	50	±25%	5	3.2±0.20	2.5±0.20	1.3±0.20
CBW201209U500T	50	0.05	100	50	±25%	3	2.0±0.20	1.2±0.20	0.9±0.20
CBW453215U380T	38	0.02	100	50	±25%	5	4.5±0.20	3.2±0.20	1.5±0.20
CBW322513U310T	31	0.03	100	50	±25%	5	3.2±0.20	2.5±0.20	1.3±0.20
CBW100505U310T	31	0.08	100	50	±25%	1.8	1.0±0.15	0.5±0.15	0.5±0.15
CBW321609U310T	31	0.04	100	50	±25%	3	3.2±0.20	1.6±0.20	0.9±0.20
CBW201209U310T	31	0.04	100	50	±25%	3	2.0±0.20	1.2±0.20	0.9±0.20
CBW160808U310T	31	0.03	100	50	±25%	3	1.6±0.20	0.8±0.20	0.8±0.20
CBW451616U310T	31	0.02	100	50	±25%	6	4.5±0.20	1.6±0.20	1.6±0.20
CBW321609U260T	26	0.04	100	50	±25%	3	3.2±0.20	1.6±0.20	0.9±0.20
CBW160808U260T	26	0.03	100	50	±25%	3	1.6±0.20	0.8±0.20	0.8±0.20
CBW453215U260T	26	0.02	100	50	±25%	5	4.5±0.20	3.2±0.20	1.5±0.20
CBW201209U260T	26	0.04	100	50	±25%	3	2.0±0.20	1.2±0.20	0.9±0.20
CBW100505U260T	26	0.06	100	50	±25%	1.8	1.0±0.15	0.5±0.15	0.5±0.15
CBW451616U260T	26	0.02	100	50	±25%	6	4.5±0.20	1.6±0.20	1.6±0.20
CBW322513U260T	26	0.03	100	50	±25%	5	3.2±0.20	2.5±0.20	1.3±0.20
CBW321609U190T	19	0.04	100	50	12～25Ω	3	3.2±0.20	1.6±0.20	0.9±0.20
CBW322513U190T	19	0.03	100	50	12～25Ω	5	3.2±0.20	2.5±0.20	1.3±0.20
CBW451616U190T	19	0.015	100	50	12～25Ω	6	4.5±0.20	1.6±0.20	1.6±0.20
CBW160808U190T	19	0.03	100	50	12～25Ω	3	1.6±0.20	0.8±0.20	0.8±0.20
CBW453215U190T	19	0.02	100	50	±25%	5	4.5±0.20	3.2±0.20	1.5±0.20
CBW100505U190T	19	0.06	100	50	12～25Ω	1.8	1.0±0.15	0.5±0.15	0.5±0.15
CBW321609U110T	11	0.04	100	50	7～15Ω	4	3.2±0.20	1.6±0.20	0.9±0.20
CBW201209U110T	11	0.02	100	50	7～15Ω	3	2.0±0.20	1.2±0.20	0.9±0.20
CBW060303X100T	10	0.05	100	50	±5Ω	1	0.6±0.03	0.3±0.03	0.3±0.03
CBW321609U090T	9	0.04	100	50	5～13Ω	4	3.2±0.20	1.6±0.20	0.9±0.20
CBW100505U070T	7	0.04	100	50	0～11Ω	1.8	1.0±0.15	0.5±0.15	0.5±0.15
CBW321609U050T	5	0.04	100	50	0～15Ω	4	3.2±0.20	1.6±0.20	0.9±0.20
CBW201209U050T	5	0.02	100	50	0～15Ω	3	2.0±0.20	1.2±0.20	0.9±0.20
